Setting system-wide Environment Variables on MacOS

This will be a nice quick one, something I’ve discovered recently that is barely documented!

Problem

#

You need to set environment variables at the system level on MacOS, so that all processes running after boot up will have access to those variables.

To make the point concrete, let’s use a motivating example: XDG_CONFIG_HOME

The value of this environment variable points to a particular directory that applications can use to store settings and other configuration files. Most people end up setting this to ~/.config (which is the default on Linux for this variable anyway). So an application called “blah” would store it’s config under ~/.config/blah/

I like the ~/.config convention far more than ~/Library/Application Support and it fits well with what a lot of command line programs and other dev tools assume as defaults so I want to set my XDG_CONFIG_HOME to this for my mac.

The Solution that kinda works

#

You could just put the following in your shell startup file like ~/.zshrc or ~/.config/fish/config.fish or choose your favourite shell’s path:

# ~/.zshrc
# $HOME expands to your user home dir e.g. /Users/<you>/ or ~/
export XDG_CONFIG_HOME=$HOME/.config

And you could get away with this for most things, it would work most of the time. Certainly any programs you run from within a terminal session (like most command line dev tools) would respect this value now.

But what if you want XDG_CONFIG_HOME to be set for your shell itself… or any other programs that run outside of a terminal session where ~/.zshrc hasn’t been sourced yet? 🤔

Why only “kinda”

#

This is where I was stuck!

I use nushell (it’s actually great you should check it out if you haven’t yet!) and nushell actually looks for XDG_CONFIG_HOME before it starts up to source it’s config (stored by default on macs under ~/Library/Application Support/nushell)

So setting XDG_CONFIG_HOME in ~/Library/Application Support/nushell/env.nu would work for everything started in a terminal session after nushell starts, but crucially not nushell itself

There’s even a note on this in the docs in Additional Startup Configuration :

As discussed below, variables in this section must be set before Nushell is launched.

So I had to find a way to set XDG_CONFIG_HOME before my shell (or any other user-space program for that matter) is launched

The Real Solution

#

Turns out there’s a program in MacOS called launchctl, which allows us to programmatically interact with launchd, a “System wide and per-user daemon/agent manager”.

This is how we can get MacOS to do things for us on boot, user-login etc. Crucially, buried in the man page of launchctl… is the setenv subcommand:

setenv key value
    Specify an environment variable to be set on all future processes
    launched by launchd in the caller's context.

This is getting somewhere! Now we need to get MacOS to run this for us on startup.

We do this by putting plist files in the correct places to make things happen. The place we want for this task is ~/Library/LaunchAgents, and the file is pretty simple!

<!-- ~/Library/LaunchAgents/setenv.XDG_CONFIG_HOME.plist -->
<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
  <plist version="1.0">
  <dict>
  <key>Label</key>
  <string>setenv.XDG_CONFIG_HOME</string>
  <key>ProgramArguments</key>
  <array>
    <string>/bin/launchctl</string>
    <string>setenv</string>
    <string>XDG_CONFIG_HOME</string>
    <string>/Users/tomfleet/.config</string>
  </array>
  <key>RunAtLoad</key>
  <true/>
</dict>
</plist>

You can see our launchctl setenv command there, along with the RunAtLoad key set to true (this is the crucial bit 👌🏻).

We save this file in ~/Library/LaunchAgents/setenv.XDG_CONFIG_HOME.plist and our job is done! On a restart, launchctl will arrange this to be run for us and XDG_CONFIG_HOME will point to the right place for all user-space programs 🎉

If you look at my dotfiles repo, I’ve even got this bit managed with GNU Stow so it’s automatically put in the right place 🤓 Now if I evaluate $nu.default-config-dir it gives me:

❯ $nu.default-config-dir
/Users/tomfleet/.config/nushell

Success! ✅
